Measuring Range | 0~4…60bar (nomal range) |
-1~4…100bar , 0~2…3bar , 0~61bar…600bar |
Output / Power Supply | 4~20mA / 12~30VDC (2 wire) |
0.5~4.5V / 5VDC (3 wire ) |
0/1~5V / 10~30VDC/AC (3 wire ) |
0~10V / 12~30VDC/AC (3 wire ) |
Accuracy: ±0.5%F.S?±1.0%F.S |
Stable: ±0.5%F.S, ±1.0%F.S (Max) |
Overload Capability: 1.5 times full scale |
Burst Pressure: 3 times full scale |
Response time : 10ms |
Medium Temperature Range : -40°C +100°C |
Compensated Temperature:-10°C+80°C |
Storage Temperature Range:-50°C+125°C |
Sample line connection: male G1/4, NPT1/4, M20×1.5, G1/2, 7/16-20UNF(other connection is available on request) |
Electrical Connection: Packard, DIN43650C, M12 Series, Cable |
Protection Class: IP67 |
Pressure Type: Guage pressure |
Insulation Resistance: >100MΩ@50V |
Electro Magnetic Compatibility: EN50081-1/-2; EN50082-2 |
Material | Enclosure: 1Cr18Ni9Ti Stainless Steel |
Connection: 1Cr18Ni9Ti Stainless Steel |
Wet material: Ceramic |
